INDUCTIVE SENSOR IG5579 ---> Date of discontinuation: 31-03-2017
| Electrical data |
|---|
| Operating voltage [V] | 10...36 DC |
| Current consumption [mA] | 15; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
| Outputs |
|---|
| Electrical design | PNP |
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 250 |
| Switching frequency DC [Hz] | 300 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
| Detection zone |
|---|
| Sensing range [mm] | 8 |
| Real sensing range Sr [mm] | 8 ± 10 % |
| Operating distance [mm] | 0...6.5 |
| Accuracy / deviations |
|---|
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2 |
| Hysteresis [% of Sr] | 1...15 |
| Switch point drift [% of Sr] | -10...10 |
| Operating conditions |
|---|
| Ambient temperature [°C] | -25...80 |
| Protection | IP 65 |
| Tests / approvals |
|---|
| EMC | | EN 60947-5-2 | | | EN 55011 | class B |
|
| MTTF [years] | 1853 |
| Mechanical data |
|---|
| Weight [g] | 155 |
| Housing | threaded type |
| Mounting | non-flush mountable |
| Dimensions [mm] | M18 x 1 |
| Thread designation | M18 x 1 |
| Materials | brass white bronze coated; CO-PC |
| Displays / operating elements |
|---|
| Display | | switching status | 1 x LED, yellow |
|
| Accessories |
|---|
| Accessories (supplied) | |
| Remarks |
|---|
| Notes | discontinued article |
| Pack quantity | 1 pcs. |
| Electrical connection - plug |
|---|
| Connection | Connector: 1 x Ø 28 mm |
