OFF DELAY CT-ARE (0.3-30s)

OFF DELAY CT-ARE (0.3-30s)

Giá: Liên hệ
Số lượng
- +

OFF DELAY CT-ARE (0.3-30s)

Technical

  • Timer Relay Type:
    True OFF-Delay
  • Time Range:
    0.3-30 s
  • Rated Control Supply Voltage (Us):
    110 ... 130 V AC
  • Output:
    1 c/o (SPDT) contact
  • Terminal Type:
    Screw Terminals
  • Rated Operational Current AC-12 (Ie):
    (230 V) 4 A
  • Rated Operational Current AC-15 (Ie):
    (230 V) 3 A
  • Rated Operational Current DC-12 (Ie):
    (24 V) 4 A
  • Rated Operational Current DC-13 (Ie):
    (24 V) 2 A
  • Mounting Position:
    Any
  • Mounting on DIN Rail:
    TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
    TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
  • Standards:
    EN 50581
    IEC/EN 61812-1
    UL 508
    CAN/CSA C22.2 No.14

Environmental

  • RoHS Status:
    Following EU Directive 2011/65/EU
