FOTEK MT-48 TEMPERATURE CONTROLLER
FOTEK MT-48 TEMPERATURE CONTROLLER
| Specification & Characteristic | Data | |
Power supply | 90 ~ 265 VAC 50/60 HZ | |
Power consumption | 5VA max. | |
Sensor input | K / J / PT-100Ω selectable | |
Control output | Relay | 3A / 250 VAC SPDT |
Voltage | 12V / 50mA | |
Linear | 4~20 mA ; Load: 600Ωmax. | |
Alarm output | 3A / 250 VAC SPDT | |
Control method | Fuzzy ﹢PID or ON / OFF settable | |
Operating circumstance | -20°C ~ +75°C ; 25% ~ 85% RH | |
Display accuracy | ±0.1% of FS + 1 digit | |
Cycle time | 0 ~ 99 sec | |
Proportional band (P) | 0 ~ 999 | |
Integral time (I) | 0 ~ 3999 | |
Derivative time (D) | 0 ~ 3999 | |
Alarm range | -99 ~ 999 | |
PV sampling time | 0.1 sec | |
Input shift | -99 ~ +99 | |
AT bias (TU) | 0 ~ 999 | |
Memory method | EEPROM | |
Insulation resistance | Over 50MΩ / 500VDC | |
Dielectric strength | Over 2.5kV / 1 minute | |
EMC standard | ESD: 8 KV Air Discharge (Level 3) / EN-61000-4-2 | |
